ATX GTX1660SDPG6-K4 , 4x DP 1.2 ports
|
GPU | NVIDIA GTX 1660 Super |
GPU Core Clock | 1,785 Mhz core clock |
Video Memory | 6GB GDDR5 graphics memory |
Stream Processors | 1408 SP |
Memory Clock/Bandwidth | 14Gbps GDDR5 /192-bit |
APIs supported | DirectX® 12,Supports NVIDIA NVENC Turing Encoder |
BUS Interface | PCIe® 3.0 compliant, x16 |
Form Factor | 189.75 x 111.1520.mm; ATX size , Dual-slot, |
FAN Cooler | Discreet active FAN cooler , (Dual slot, Copper Core, Temp-control FAN speed) |
Display Ports Output | 4x DisplayPort 1.2 output @4096x2160 60Hz (cable lock) supports 4x Discrete Digital Multi-Point Audio capability. (4 x DDMAs). Additional 3.3V power circuitry to support external dongles driving compatibility. DPs support up to 4x Curved UltraWide (21:9) QHD displays @3440x1440, 2560x1080 resolution wide screen displaying* |
Maximum Resolution | Maximum DisplayPort 1.2 resolution of 4096 x 2160, 24 bits per pixel at 60Hz. Eyefinity resolution supported : 2160x11520 resolution 60Hz (Eyefinity 1x4 mode) 7680 x 4320 resolution 60Hz (Eyefinity 2x2 mode) (4K x 4) 11520 x 2160 resolution 60Hz (Eyefinity 4x1 mode) *Supports 4x1,1x4,2x2 Surround mode with 4x Curved UltraWide (21:9) QHD displays @3440x1440, 2560x1080 resolution Wide screen displaying* Support Custom Resolution 3840 x 600@60Hz or more : |
Power Consumption | < 125W (8-pin external power input required) |
Accessories | CD Driver, Quick Installation Manual. |
O/S support | - Windows® 10 |
Feature Summary | No Video Tearing effect supported:
|
